Renaissance Fittings & Piping is a 5052 H32 aluminium sheets manufacturer and supplier in India, supplying Aluminium 5052 H32 sheets for industrial fabrication, transportation, marine-related components, enclosures, chemical equipment and general engineering applications.
5052 H32 is a non-heat-treatable aluminium alloy supplied in a strain-hardened condition, offering a useful combination of corrosion resistance, strength, weldability and formability. Sheets can be supplied in required thicknesses, widths, lengths and surface conditions according to the applicable material specification.
5052 H32 Aluminium Sheet Specifications
| Specification | Details |
|---|---|
| Aluminium Grade | 5052 |
| Temper | H32 |
| UNS | A95052 |
| EN Designation | EN AW-5052 |
| Alloy Designation | AlMg2.5 |
| Product Form | Aluminium Sheet |
| ASTM Standard | ASTM B209 |
| ASME Standard | ASME SB209 |
| AMS Standard | AMS 4016 |
| QQ Specification | AMS-QQ-A-250/8 |
| Heat Treatment | Non-heat-treatable |
| Density | 2.68 g/cm³ |
| Surface | Mill Finish / As Specified |
5052 H32 Aluminium Sheet Sizes and Dimensions
| Parameter | Reference Range / Size |
|---|---|
| Thickness | 0.40–8.00 mm |
| Width | 16–1500 mm |
| Length | 1000–12000 mm |
| Common Sheet Size | 1220 × 2440 mm |
| Common Sheet Size | 1500 × 3000 mm |
| Product Form | Sheet |
| Surface | Mill Finish |
5052 H32 Aluminium Sheet Chemical Composition
| Element | Composition % |
|---|---|
| Magnesium (Mg) | 2.20–2.80 |
| Chromium (Cr) | 0.15–0.35 |
| Iron (Fe) | 0.00–0.40 |
| Silicon (Si) | 0.00–0.25 |
| Copper (Cu) | 0.00–0.10 |
| Manganese (Mn) | 0.00–0.10 |
| Zinc (Zn) | 0.00–0.10 |
| Other, Each | 0.00–0.05 |
| Other, Total | 0.00–0.15 |
| Aluminium | Balance |
5052 H32 Aluminium Sheet Mechanical Properties
| Thickness | Tensile Strength | Minimum Proof Stress | Minimum Elongation |
|---|---|---|---|
| 0.40–1.00 mm | 210–260 MPa | 160 MPa | 7% |
| >1.00–3.00 mm | 210–260 MPa | 130 MPa | 9% |
| >3.00–8.00 mm | 210–260 MPa | 130 MPa | 10% |
5052 H32 Aluminium Sheet Hardness
| Property | Value |
|---|---|
| Brinell Hardness | 60 HB |
5052 H32 Aluminium Sheets Standards and Designations
| Standard / Designation | Details |
|---|---|
| ASTM | ASTM B209 |
| ASME | ASME SB209 |
| AMS | AMS 4016 |
| QQ Specification | AMS-QQ-A-250/8 |
| UNS | A95052 |
| EN | EN AW-5052 |
| Alloy Designation | AlMg2.5 |
5052 H32 Aluminium Sheets Applications
5052 H32 aluminium sheets are selected for applications requiring a combination of corrosion resistance, strength, formability and weldability.
- Sheet metal fabrication
- Electrical and equipment enclosures
- Cabinets and panels
- Transportation components
- Fuel tanks and fuel-related components
- Marine-related fabrication
- Chemical processing equipment
- Appliances
- Lighting components
- General engineering components
- Fabricated aluminium structures
- Industrial equipment
5052 H32 Aluminium Sheets Supplier in India
Renaissance Fittings & Piping supplies 5052 H32 aluminium sheets for industrial buyers, fabricators, engineering companies and manufacturing requirements in India.
When requesting a quotation, provide the required thickness, width, length, quantity, surface condition and applicable material standard so the correct 5052 H32 aluminium sheet specification can be identified.
Explore 5052 & 5754 Aluminium Sheets and Plates
For buyers looking for other aluminium sheet grades within the same material range, explore our 5052 & 5754 Aluminium Sheets and Plates category for additional alloy and temper options.
