Renaissance Fittings & Piping is a trusted 5083 Aluminium Chequered Plates supplier and stockist in India, offering premium-quality ASTM B209 / ASME SB209 Aluminium 5083 Chequered Plates for marine, offshore, transportation and industrial applications. Our chequered plates are available in a wide range of sizes, tempers and finishes, ensuring reliable performance in environments that demand exceptional corrosion resistance, strength and durability.
Aluminium Alloy 5083 is one of the highest-strength non-heat-treatable aluminium alloys, renowned for its outstanding resistance to seawater corrosion, excellent weldability and superior mechanical properties. We supply Hot Rolled (HR) and Cold Rolled (CR) Aluminium 5083 Chequered Plates with mill finish and customer-specific finishes, along with customised dimensions and coating options to meet diverse engineering and fabrication requirements.
Why Choose Aluminium 5083 Chequered Plates?
Aluminium Alloy 5083 is widely recognised for its outstanding corrosion resistance, high mechanical strength and excellent performance in harsh marine and industrial environments. The raised chequered pattern provides superior slip resistance, making these plates ideal for flooring, walkways, stair treads and transportation equipment where safety and durability are critical.
In addition to their excellent structural properties, Aluminium 5083 Chequered Plates offer outstanding weldability and fabrication characteristics, allowing them to be easily processed into customised components without compromising strength. Their lightweight construction also helps reduce overall structural weight while maintaining long-term performance in demanding applications.
Exceptional Marine Corrosion Resistance
Aluminium 5083 offers excellent resistance to seawater, saltwater spray and aggressive industrial environments, making it one of the preferred alloys for marine structures, offshore platforms, shipbuilding and coastal infrastructure.
High Strength for Heavy-Duty Applications
With superior mechanical strength compared to many standard aluminium alloys, Aluminium 5083 Chequered Plates are ideal for heavy engineering, transportation equipment, structural platforms and industrial flooring that require reliable load-bearing performance.
Anti-Skid Surface for Safe Flooring
The embossed chequered pattern improves traction under wet, oily and dry conditions, reducing the risk of slips and enhancing safety in factories, warehouses, marine vessels, loading ramps and public access areas.
Excellent Weldability and Fabrication
Aluminium 5083 Chequered Plates can be easily welded, cut and fabricated into complex structures while maintaining excellent mechanical properties. This makes them suitable for customised engineering projects, heavy fabrication and industrial equipment manufacturing.
Aluminium 5083 Chequered Plates Specifications
Our ASTM B209 Aluminium 5083 Chequered Plates are manufactured to meet international quality standards, ensuring consistent performance, dimensional accuracy and long service life. We stock these chequered plates in various tempers, sizes and surface finishes to support marine engineering, shipbuilding, transportation, construction and industrial fabrication projects.
| Specification | Details |
|---|---|
| Material Grade | Aluminium Alloy 5083 |
| Standards | ASTM B209 / ASME SB209 |
| Temper | O, H12, H14, H16, H18, H19, H22, H24, H26, H28, H32, H34, H36, H38, H111, H112, H114, H116, H321 |
| Thickness | 0.5 mm to 300 mm |
| Width | 100 mm to 2600 mm |
| Length | 500 mm to 10000 mm |
| Type | Hot Rolled (HR) / Cold Rolled (CR) Chequered Plates |
| Surface | Bright, Polished, Hairline, Brush, Sand Blast, Embossed, Etched |
| Finish | Mill Finish, Customer Specific Finish |
| Coating Options | PVC Coated, Colour Coated, Polyester, Fluorocarbon, Polyurethane and Epoxy Coating |
Aluminium 5083 Chequered Plates Equivalent Grades
Aluminium Alloy 5083 is manufactured in accordance with internationally recognised standards, enabling seamless material selection across global engineering specifications. The following table lists the commonly accepted equivalent grades for Aluminium 5083 Chequered Plates.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | Germany (DIN) |
|---|---|---|---|---|---|---|
| AW-AlMg4,5Mn0,7 | AG4,5MC | 3.3547 | A95083 | AlMg4,5Mn0,7 | 5083 | AlMg4,5Mn |
Types of Aluminium 5083 Chequered Plates We Supply
Renaissance Fittings & Piping supplies Aluminium 5083 Chequered Plates in both Hot Rolled (HR) and Cold Rolled (CR) forms to meet the requirements of marine engineering, offshore construction, transportation equipment and heavy industrial fabrication. Both variants provide exceptional corrosion resistance, structural strength and a durable anti-slip surface for demanding operating environments.
Aluminium 5083 Hot Rolled Chequered Plates
Aluminium 5083 Hot Rolled Chequered Plates are manufactured through a controlled hot rolling process that enhances structural integrity and mechanical strength. These plates are widely used in shipbuilding, offshore platforms, truck flooring, loading ramps and industrial walkways where heavy-duty performance and long-term durability are essential.
The hot rolled process also delivers excellent weldability and fabrication characteristics, making these chequered plates suitable for large structural components and demanding engineering applications exposed to harsh environments.
Aluminium 5083 Cold Rolled Chequered Plates
Aluminium 5083 Cold Rolled Chequered Plates are processed at room temperature to achieve improved dimensional accuracy, tighter tolerances and a smoother surface finish. These properties make them ideal for precision fabrication, transportation equipment, architectural flooring and industrial applications where both appearance and performance are important.
Cold rolled Aluminium 5083 Chequered Plates are commonly selected for projects requiring consistent thickness, superior surface quality and excellent corrosion resistance while maintaining the high strength characteristics of Aluminium Alloy 5083.
Aluminium 5083 Chequered Plates Chemical Composition
The chemical composition of Aluminium Alloy 5083 Chequered Plates is designed to deliver exceptional corrosion resistance, superior strength and excellent weldability. Its high magnesium content provides outstanding resistance to seawater and aggressive industrial environments, making it one of the preferred aluminium alloys for marine, offshore and heavy-duty structural applications.
The table below outlines the standard chemical composition of Aluminium 5083 Chequered Plates.
| Element | Composition |
|---|---|
| Aluminium (Al) | Balance |
| Silicon (Si) | 0.40% Max |
| Iron (Fe) | 0.40% Max |
| Copper (Cu) | 0.10% Max |
| Manganese (Mn) | 0.40 – 1.00% |
| Chromium (Cr) | 0.05 – 0.25% |
| Magnesium (Mg) | 4.00 – 4.90% |
| Titanium (Ti) | 0.15% Max |
| Zinc (Zn) | 0.25% Max |
| Other Elements (Each) | 0.05% Max |
| Other Elements (Total) | 0.15% Max |
Mechanical Properties of Aluminium 5083 Chequered Plates
Aluminium Alloy 5083 offers an excellent combination of high strength, good ductility and outstanding corrosion resistance, making it suitable for applications that demand reliable structural performance in harsh operating environments. Its mechanical properties make it particularly well suited for marine construction, transportation equipment and industrial flooring systems.
The following table represents the typical mechanical properties of Aluminium 5083 Chequered Plates.
| Property | Value |
|---|---|
| Proof Stress | 125 MPa Min |
| Tensile Strength | 275 – 350 MPa |
| Hardness (Brinell) | 75 HB |
| Elongation | 12% Min |
Standard Specifications for Aluminium 5083 Chequered Plates
Our Aluminium 5083 Chequered Plates are manufactured in accordance with internationally recognised industry standards to ensure consistent quality, dimensional accuracy and dependable performance. These specifications define the manufacturing, testing and inspection requirements for aluminium chequered plates used in marine, structural and industrial applications.
| Standard | Description |
|---|---|
| ASTM B209 | Standard specification covering aluminium and aluminium-alloy chequered plates, including chemical composition, dimensional tolerances and mechanical properties. |
| ASME SB209 | ASME equivalent of ASTM B209, commonly specified for marine, engineering and industrial fabrication applications. |
| ASTM B632 / B632M | Standard specification covering aluminium alloy rolled tread (chequered) plates used for industrial flooring and structural applications. |
| ASTM B947 | Standard practice for hot rolling and solution heat treatment of aluminium alloy products to ensure consistent metallurgical properties. |
| ASTM B548 | Standard test method for ultrasonic inspection of aluminium alloy plates used in critical engineering applications. |
| AMS 4001 | Aerospace Material Specification covering annealed aluminium plate products for precision engineering applications. |
| AMS 4003 | Covers strain-hardened aluminium alloy plate products with controlled mechanical properties. |
| AMS QQA250/1 | Material specification defining quality and acceptance requirements for aluminium alloy products. |
Industrial Applications of Aluminium 5083 Chequered Plates
Aluminium 5083 Chequered Plates are widely used in industries that require exceptional corrosion resistance, high mechanical strength and a reliable anti-slip surface. Their ability to withstand harsh marine and industrial environments makes them an ideal choice for heavy-duty structural and flooring applications.
Common applications include:
- Shipbuilding and marine decks
- Offshore platforms and oil rigs
- Boat and ferry flooring
- Truck and trailer flooring
- Railway coach flooring
- Industrial walkways and access platforms
- Stair treads and safety flooring
- Loading ramps and dock areas
- Construction and infrastructure projects
- Chemical processing plants
- Oil and gas facilities
- Material handling equipment
- Heavy engineering fabrication
- Architectural flooring and wall panels
- General industrial and structural applications
Why Choose Renaissance Fittings & Piping for Aluminium 5083 Chequered Plates?
Renaissance Fittings & Piping is a leading 5083 Aluminium Chequered Plates supplier and stockist in India, delivering premium-quality products for marine, offshore, transportation and industrial applications. We maintain a comprehensive inventory of ASTM B209 / ASME SB209 Aluminium 5083 Chequered Plates in various sizes, tempers and finishes, enabling us to fulfil both standard requirements and customised project specifications with prompt delivery.
Every Aluminium 5083 Chequered Plate supplied by us is sourced from trusted manufacturers and undergoes stringent quality inspections to ensure compliance with international standards. Our experienced team provides technical support, competitive pricing and reliable logistics, making us the preferred partner for OEMs, contractors, engineering companies and fabrication industries across India.
Our Supply Advantages
- Large ready stock of Aluminium 5083 Chequered Plates
- Manufactured to ASTM B209 / ASME SB209 standards
- Available in Hot Rolled (HR) and Cold Rolled (CR) variants
- Wide range of thicknesses, widths and lengths
- Custom cutting and customer-specific finishes available
- PVC coated and colour-coated chequered plates supplied
- Mill Test Certificates (MTC) provided upon request
- Secure export-worthy packaging for safe transportation
- Competitive pricing for bulk and project requirements
- Fast delivery across major industrial cities in India
- Technical assistance for material selection and fabrication requirements
Major Industrial Cities We Supply
Renaissance Fittings & Piping supplies Aluminium 5083 Chequered Plates across India's leading industrial hubs, serving shipbuilding companies, fabrication industries, construction contractors, OEM manufacturers and engineering organisations. Our efficient logistics network enables timely delivery for both small and large-volume orders throughout the country.
| West India | North India | South India | East & Central India |
|---|---|---|---|
| Mumbai | Delhi | Chennai | Kolkata |
| Pune | Noida | Bengaluru | Patna |
| Nashik | Gurugram | Hyderabad | Ranchi |
| Nagpur | Faridabad | Coimbatore | Bhopal |
| Ahmedabad | Chandigarh | ||
| Vadodara | Ludhiana | ||
| Surat | Jaipur | ||
| Rajkot | Indore |
Related Aluminium Chequered Plate Grades
Explore our complete range of aluminium chequered plates designed to meet diverse engineering, marine and industrial requirements:
Each aluminium alloy offers distinct advantages in terms of strength, corrosion resistance, weldability and fabrication performance, allowing engineers and procurement professionals to select the most suitable chequered plate for their specific application.
Request a Quote for Aluminium 5083 Chequered Plates
Looking for a reliable 5083 Aluminium Chequered Plates supplier and stockist in India? Renaissance Fittings & Piping offers premium-quality Aluminium 5083 Chequered Plates manufactured to international standards for marine, offshore, transportation, construction and industrial applications. Contact our team today to receive a competitive quotation, expert technical guidance and prompt delivery anywhere in India.
To help us provide an accurate quotation, please share the following details:
- Required temper
- Plate thickness
- Width and length
- Quantity required
- Surface finish or coating requirements
- Delivery location
